RAVENOL GHA-F Gearbox Hydraulic Actuator Transmission Fluid is a special hydraulic fluid based on synthetic and mineral oils blended with non-ash forming additives. It was developed for use as a special hydraulic fluid in electro-hydraulic gearboxes and electrically controlled gears and gearshifts.
Application
RAVENOL GHA-F Transmission Fluid was designed for use in electrically controlled MCP automatic transmissions from Peugeot/ Citroen and in Dualogic and Selespeed automatic transmission from Fiat/ Alfa Romeo. It is suitable for use in temperatures ranging from -40°C to +100°C.
Meets/ Exceeds Requirements
- Peugeot/ Citroen 9979.A4 for MCP Automated Gearbox
- FIAT 14621616
- FIAT 9.55550-SA1
- FIAT Nr.F005.F98
- FIAT / Alfa Romeo 15081616 CS SPEED for Dualogic
- Suzuki 99000M24121-135
- Suzuki Actuator Fluid
- Vauxhall / Opel 93165151
RAVENOL GHA-F Transmission Fluid offers:
- Extremely low pour point.
- Improved viscosity and friction value characteristics.
- Very good wear protection.
- An excellent thermal stability.
- Improved EP properties.
- Good foaming characteristics.
- Neutral behaviour towards sealing compounds.
- Reliable protection against corrosion.
| Characteristics | Unit | Data | Audit |
| Density at 20°C | kg/m³ | 827.0 | EN ISO 12185 |
| Colour | | clear, green | visual |
| Viscosity at 100°C | mm²/s | 6.65 | DIN 51562 |
| Viscosity at 40°C | mm²/s | 19.7 | DIN 51562 |
| Viscosity index VI | | 333 | ISO 2909 |
| Pourpoint | °C | -54 | DIN ISO 3016 |
| Flash point (COC) | °C | 164 | DIN ISO 2592 |
All indicated data are approximate values and are subject to commercial fluctuations.
