Information

RAVENOL TTC Traditional Technology Coolant (Antifreeze) Concentrate is an eco-friendly 1.2- Ethanediol (monoethylene glycol) based nitrite, amine and phosphate-free coolant for cooling circuits in combustion engines which provides maintenance-free corrosion and frost protection. The product is formulated as a long-term coolant based on a proven inhibitor development. The quality of an antifreeze is no longer just determined by the antifreeze effect (which automatically exists in an ethylene-glycol based product), but by the level of rust protection. That is why car manufacturers subject an antifreeze to lengthy corrosion and cavitation tests before approving its use.

RAVENOL TTC Coolant Concentrate is suitable for most motorbikes, older cars and trucks. It is also used by many Motorhome / Caravan workshops for the ALDE central heating system.

Mixing chart:

Antifreeze protection to approx.          Parts antifreeze                Parts water

           - 12°C                                                                     25 %                                    75 %

           - 20°C                                                                     35 %                                   65 %

           - 37°C                                                                    50 %                                   50 %

Meets/ Exceeds Requirements
  • AFNOR R15-601 (France)
  • ASTM D 2570
  • ASTM D1384
  • ASTM D2809
  • ASTM D3306 Type 1
  • ASTM D4985
  • ASTM D6210 Type 1-FF
  • BS 6580 (GB)
  • Chrysler MS-7170
  • CUNA NC 956-16 (Italy)
  • Fiat 9.55523
  • Fiat PARAFLU 11
  • Ford WSSM97B51-A1
  • IVECO 18-1830
  • JIS K 2234 (Japan)
  • MAN 324 NF
  • O Norm V 5123 (Austria)
  • SAE J1034
  • Suzuki
  • UNE 25-361 (Spain)
  • VW TL 774-C (meets G11)

Characteristics

RAVENOL TTC Coolant Concentrate offers:

  • Excellent for all-aluminium engines
  • Premium corrosion additives for optimal rust protection for all metals and metal alloys used in cooling systems, including aluminium
  • Good reserve alkalinity
  • High-quality corrosion additives for optimal corrosion protection
  • Compatible with elastomers used in automotive radiators
Data Sheets

Technical Product Data

Property Unit Data Audit
Density at 20 °C kg/m³ 1130,0 EN ISO 12185
Colour   gelb-grün fluoreszent VISUELL
Flashpoint °C 112 DIN 51758
pH - value at 20 °C (50 Vol %)   8,4 ASTM D1287
Reserve alkalinity ml0,1nHCl  <20 ASTM D1121
Freezing point (50 % solution) °C -37 ASTM D1177
Boiling point °C 155 ASTM D1120
Water content Gew. % <5 ASTM D1123

All indicated data are approximate values and are subject to the commercial fluctuations.

DOWNLOAD PDFSAFETY DATA SHEET

Please note that the technical data is correct at the time of writing, Ravenol are continuously updating product specifications. Therefore, please refer to the 'Download PDF' and 'Safety Data sheet' links above for up-to-date information.
